Diaphragm motor Beta 521 & 512 (A8114)

BERU spark plug connector / 1 kΩ interference suppressed

Manufacturer: BERU · Material: Sheet metal (steel) · Ø cable: 5 mm · Ø cable: 7 mm · Spark plug socket: M4 · Color: silver · Cable available: No · Suppressed: Yes · Resistance: 1000 Ω · Component group Carburetor: Spark plug connector · Pony OEM number: A2099 · Sachs OEM no.: 0265 100 00

Motorex Automatic Motor Oil (ATF) 450 ml

Manufacturer: Motorex · Contents [ml]: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -45 - 200 °C · Area of application: Gearbox lubrication with clutch · Pony OEM number: A2080 · Sachs OEM no.: 0263 014 002

Motorex engine oil 450 ml | Pony / Cilo Beta 521 Automatic

Manufacturer: Motorex · Oil type: ATF Dexron 3 (DEXIII) · Contents [ml]: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -36 - 200 °C · Area of application: Gearbox lubrication with clutch

Dell'Orto air filter screen SHA

Manufacturer: Dell'Orto · Material: Steel · Surface: galvanized (blue) · Color: silver · Ø outside: 56 mm · Height: 13 mm · Area of application: Standard

Intake gasket, engine Beta 521 & 512 (A8100)

Manufacturer: Pony · Material: Sealing carton · Surface: coated · Place of use: Admission · Thickness: 2 mm · Hole spacing inlet: 35 mm

Diaphragm seal engine Beta 521 & 512 (A8101)

Manufacturer: Pony · Place of use: Admission · Thickness: 2 mm · Hole spacing inlet: 35 mm · Ø screw holder: 6.6 mm · Area of application: Standard

NGK B6ES spark plug long thread

Manufacturer: NGK · Candle designation: B6ES · Candle thread type: long · Thread type: MF14x1.25 (fine pitch thread) · Spark plug socket: M4 · Spark plug socket: SAE · Suppressed: No · Width across flats SW: 21 mm · Area of application: Original · Area of application: Standard

Exhaust gasket exhaust | Beta 521 & 512 (A8099)

Manufacturer: Pony · Material: Sealing carton · Material: Sheet metal (steel) · Place of use: Exhaust · Reinforced: Yes · Ø inside: 21.8 mm · Thickness: 1.7 mm · Ø screw holder: 6 mm · Area of application: Standard

Dell'Orto 13/11 SHA Spaco carburetor hand choke

Manufacturer: Dell'Orto · Camouflaged: No · Component group Carburetor: Carburetor complete · Material: Aluminum · Color: black · Carburetor type: SHA (Piaggio) · Nominal diameter: 11 mm · Nominal diameter: 13 mm · Ø Internal connection: 16 mm · Ø without reducing sleeve: 18 mm · Ø Inside entrance: 11 mm · Ø Output inside: 13 mm · Ø Air filter connection: 59 mm · Ø fuel hose connection: 5.2 mm · Ø fuel hose connection: 6 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M5x0.8 (standard thread) · Nozzle size: 48 · Mounting type: Plug connection clamped · Total length: 52 mm · Width: 65 mm · Height: 99 mm · Area of application: Original · Area of application: Tuning

Insulating bushing carburetor engine | Beta 521, 512 (A8163)

Manufacturer: Pony · Material: Plastic · Component group Carburetor: Adjusting screws, float, etc. · Color: black · Carburetor type: SHA · Carburetor type: SHA (Piaggio) · Ø inside: 16 mm · Ø outside: 17.8 mm
