Puch engine & gearbox

swiing® revival thrust washer 12.5/18/2 gearbox | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 2 mm

swiing® revival thrust washer 15/22/1.7 clutch | Puch E50, Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 15 mm · Ø outside: 22 mm · Thickness: 1.7 mm · Puch OEM number: 050.1213

swiing® revival gearbox cover gasket (new model) | Puch Z50 engine

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 170 mm · Width: 120 mm · Thickness: 0.35 mm · Number of fixing points: 7 pcs

swiing® ingenious needle roller bearing 12/15/16.2 "Racing" silver cage

Bearing type: Needle roller and cage assembly · Bearing cage: Silver cage · Dimension needle bearing: 12/15 x 16.2 · Ø inside: 12 mm · Ø outside: 15 mm · Manufacturer: swiing® ingenious parts · Width: 16.2 mm · Tomos OEM number: 035548

swiing® revival plain bearing clutch basket | Puch E50

Ø inside: 15 mm · Nominal diameter inside: 15 mm · Ø outside: 17 mm · Total height: 21.75 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze

swiing® revival thrust washer 12.5/18/2.5 gearbox | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 2.5 mm

GPO clutch plates (pair) | Puch X30

Manufacturer: GPO · Number of slats: 2 pcs · Area of application: Standard

Rubber kickstarter original | Puch

Material: Rubber

Jasil crankshaft | Puch 3- & 4-speed models

Manufacturer: Jasil · Total length of crankpin on clutch side: 73 mm · Number of gears: 3 pcs · Number of gears: 4 pcs · Area of application: Standard

Shim 17/25/0.2 Crankshaft L17 Bearing | Puch

Ø inside: 17 mm · Nominal diameter inside: 17 mm · Ø outside: 25 mm · Thickness: 0.2 mm · Manufacturer: Puch · Material: Steel · Surface: blank / oiled

Shim 17/24/0.1 Crankshaft L17 Bearing | Puch

Ø inside: 17 mm · Nominal diameter inside: 17 mm · Ø outside: 25 mm · Thickness: 0.1 mm · Manufacturer: Puch · Material: Steel · Surface: blank / oiled

Shim 17/24/0.3 Crankshaft L17 Bearing | Puch

Nominal diameter inside: 17 mm · Ø outside: 24 mm · Manufacturer: Puch · Material: Steel · Surface: blank / oiled · Thickness: 0.3 mm · Ø inside: 17 mm

swiing® revival clutch shaft Ø 14 mm | Puch E50

Manufacturer: swiing® revival parts · Total length: 79.2 mm · Ø outside: 13.95 mm · Area of application: Standard

Rito Crankshaft Racing | Puch E50

Manufacturer: Rito · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 43 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 67 mm · Ø crank webs: 69.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 11 mm · Thread length: 14 mm · Dimension needle bearing: 12 / 15 x 15 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Length 3rd paragraph: 25 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Weight: 970 g · Number of gears: 1 pcs · Area of application: Racing · Area of application: Tuning

swiing® revival snapping spring | Puch Z50

Spring design: Pressure spring · Manufacturer: swiing® revival parts · Puch OEM number: 320.1.14.023.1

swiing® revival gasket set engine | Puch Maxi S - 2A (ZA50 engine)

Manufacturer: swiing® revival parts · Number of components: 10 pcs · Hole spacing inlet: 32 - 38 mm · Ø outlet inside: 22 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 · Area of application: Standard

Oil seal NBR 16/28/7 BS Kickstarter | Puch Z50

Temperature resistance (min.): -30 - 100 °C · Simmering type: BS - With sheet metal outer casing / one sealing lip / one dust lip. · Ø inside: 16 mm · Ø outside: 28 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR

Silicone seal Ø 45 x 2 silencer | Puch

Place of use: Exhaust · Ø inside: 45 mm · Ø outside: 52 mm · Manufacturer: Puch · Material: Silicone · Thickness: 2.9 mm · Nominal diameter: 45 mm · Area of application: Standard

swiing snapper to gearshift | Puch Z50

Manufacturer: swiing · Material: Steel · Surface: gas nitrided · Puch OEM number: 050.1.1421

HK clutch "Racing" Aramid | Puch E50

Manufacturer: HK Clutches · Material: Steel · Material addition: Chrome steel (known as Nirosta®) · Recording type: Cone mounting · Number of jaws: 3 pcs · Number of springs: 3 pcs · Area of application: High End · Area of application: Performance · Area of application: Racing · Area of application: Tuning

swiing® revival fitting sleeve engine housing | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Ø outside: 10 mm · Total length: 20 mm

Oil seal NBR 22/40/7 AS crankshaft | E50

Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 22 mm · Ø outside: 40 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized

Crescent ring clutch shaft Puch E50

Fuse type: Outside · Place of use: Clutch · Manufacturer: Puch

Centering screw M22x1.5 plastic | Puch Z50

Material: Plastic · Nut type: Hexagon nut · Thread type: MF22x1.5 (fine pitch thread) · Drive: External hexagon · Puch OEM number: 329.1.12.133.1

Drive gear 69 teeth Occ. | Z50

Manufacturer: Puch · Toothing type: helical toothed · Number of teeth: 69 pcs

Clutch Surflex Puch Supermaxi E50 (long pads)

swiing oil drain plug | Puch ZA50

Manufacturer: swiing · Material: Steel · Surface: galvanized (blue) · Screw head: Hexagon · Drive: External hexagon · Puch OEM number: 321.1.10.670.1

Gasket cylinder base 1.5 mm | Puch

Place of use: Cylinder base · Thickness: 1.5 mm

Jasil connecting rod | Puch

Manufacturer: Jasil · Material: Steel · Surface: copper-coated · Connecting rod length center-center: 90 mm · Total length: 114.5 mm · Ø piston pin (B): 12 mm · Ø Connecting rod bolt: 14 mm · Ø lower connecting rod eye outside: 24.6 mm · Ø upper connecting rod eye outside: 20.9 mm · Ø lower bearing inside: 18 mm · Ø inside upper bearing: 15 mm · Dimension lower bearing: 14/15 x 9.75 mm · Dimension upper bearing: 12/15 x 14.7 mm · Connecting rod pin length: 34 mm · Thickness: 10 mm · Area of application: Standard · Area of application: Tuning

GPO reinforcement plate 1.5 mm clutch (2-/ 3-jaw) Inox | Puch E50

Manufacturer: GPO · Material: Chrome steel (known as Nirosta®) · Ø inside: 40 mm · Ø outside: 90.5 mm · Height: 1.5 mm · Area of application: Road use

O-ring oil drain ZA50 large

Place of use: Outlet · Cord thickness: 2.5 mm · Color: black · Manufacturer: Puch · Ø inside: 11 mm · Ø outside: 16 mm · Puch OEM number: 901.3784

O-ring oil drain ZA50 small

Place of use: Outlet · Cord thickness: 2.4 mm · Color: black · Manufacturer: Puch · Ø inside: 4.2 mm · Ø outside: 9 mm · Puch OEM number: 900.3797

Oil seal NBR 17/28/7 AS Pinion shaft | Puch Z50

Place of use: Pinion shaft · Temperature resistance (min.): -30 - 100 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 17 mm · Ø outside: 28 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized · Area of application: Standard

Gilardoni italkit diaphragm seal | Puch

Manufacturer: Gilardoni italkit · Material: Sealing paper · Place of use: Admission · Thickness: 0.5 mm · Hole pattern [mm]: 34 x 60 · Area of application: Racing · Area of application: Tuning

swiing® revival nut & washer for clutch (kickstart) | Puch E50

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Thread type: MF10x1 (fine pitch thread) · Drive: External hexagon · Height: 5 mm · Width across flats SW: 19 mm · Strength class: 8

Clutch basket 21 teeth kickstarter | Puch E50

Surflex clutch 1st gear | Puch ZA50

Manufacturer: Surflex · Material: Composite materials · Material: Steel · Recording type: Interlocking · Number of jaws: 3 pcs · Number of springs: 3 pcs · Ø inside: 14 mm · Ø inside: 17 mm · Ø outside: 83.5 mm · Thickness: 12 mm · Area of application: Original · Area of application: Standard

GPO gasket set | Puch E50

Manufacturer: GPO · Material: Aluminum · Material: Fiber · Material: Sealing carton · Material: Sealing paper · Number of components: 7 pcs · Hole spacing inlet: 32 - 38 mm · Ø outlet inside: 19.9 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 · Decompressor: Yes · Area of application: Standard

swiing® revival clutch spring 2-disc version (Version 2.0) | Puch Z50

Spring design: Pressure spring · Ø wire: 4 mm · Ø inside: 30.5 mm · Ø outside: 39 mm · Total length: 19.5 mm · Color: gray · Manufacturer: swiing® revival parts · Number of components: 1 pcs · Material: Spring steel · Surface: raw · Area of application: Original · Area of application: Standard

swiing® revival gearbox cover gasket | Puch Maxi S LG2 ZA50 engine

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 175 mm · Width: 133 mm · Thickness: 0.3 mm · Number of fixing points: 6 pcs

swiing® revival thrust washer 12.5/18/1.4 gearbox | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 1.4 mm

Clutch hub Z50 engine Occ. | X30 Sport, Velux

Manufacturer: Puch · Recording type: Interlocking · Toothing type: straight toothed · Area of application: Original

Ignition rubber | Puch E50

Material: Rubber · Ø inside: 2.5 mm · Ø inside 2: 5 mm · Waistband height: 2.5 mm · Total length: 30.3 mm · Width: 15 mm · Height: 11 mm · Total height: 15 mm · Color: black

Jasil crankshaft full cheeks (new model) | Puch E50

Manufacturer: Jasil · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 43 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 67 mm · Ø crank webs: 69.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 10 mm · Thread length: 13.5 mm · Dimension needle bearing: 12 / 15 x 14.7 mm (axe 12) · Wide crank webs: 34.3 mm · Length 1st paragraph: 23.3 mm · Length 2nd paragraph: 25 mm · Ø 1st step (on the coupling side): 17 mm · Ø 2nd shoulder (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Weight: 964 g · Number of gears: 1 pcs · Area of application: Racing

Shaft seal NBR 16/25/7 A Kickstarter | Puch E50

Temperature resistance (min.): -30 - 100 °C · Simmering type: A - With rubberized outer part / one sealing lip. · Ø inside: 16 mm · Ø outside: 25 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized

O-ring selector shaft Z50

Place of use: Shift shaft · Ø inside: 8.3 mm · Ø outside: 13.1 mm · Cord thickness: 2.4 mm · Hardness [Shore]: 70 Shore · Color: black · Manufacturer: Puch · Number of components: 1 pcs · Material: NBR

O-ring decoupling shaft Z50 Ø 6 x 1.5 mm

Place of use: Uncoupling shaft · Ø inside: 6 mm · Ø outside: 9 mm · Cord thickness: 1.5 mm · Manufacturer: Puch

Gasket cylinder base 2 mm | Puch

Material: Sealing carton · Place of use: Cylinder base · Thickness: 2 mm · Nominal diameter: 49 mm · Ø inside: 49 mm · Hole pattern [mm]: 44 x 44

swiing® revival neck nut M7 fan cover | Puch X30 Velux

Manufacturer: swiing® revival parts · Nut type: Neck nut · Thread type: M7x1 (standard thread) · Drive: External hexagon

Motor cable routing | Z50

Puch OEM number: 128.6305
