Nut M6 square Inox

Nut M6 extra high galvanized

Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Nut type: Hexagon nut 3D · Thread type: M6x1 (standard thread) · Drive: External hexagon · Height: 18 mm · Width across flats SW: 10 mm

Loctite 243 medium-strength threadlocker 10 ml

Temperature resistance (min.): -75 - 200 °C · Manufacturer: Loctite · Material to be used: Aluminum · Material to be used: Metal · Material to be used: Steel · Hazard warning: Causes serious eye irritation · Hazard warning: Causes skin irritation · Hazard warning: Harmful to aquatic organisms (with long-term effects) · Hazard warning: May cause allergic skin reactions · Hazard warning: May irritate the respiratory tract · Contents [ml]: 10 ml · Signal word: Attention · Hazard pictogram: GHS07 - Caution dangerous · Hazard pictogram: GHS09 - Hazardous to the aquatic environment · Area of application: Chemistry · Adhesion: medium strength · Gap dimension (max.): 0.01 mm · Type of application: 1K · Alignment time: 600 sec · Color: blue · Breakaway torque (according to material): 3 N/m · Breakaway torque (according to material): 12 N/m · Breakaway torque (according to material): 26 N/m

Stop nut M6 Inox

Material: Chrome steel (known as Nirosta®) · Nut type: Self-securing nut · Thread type: M10x1.5 (standard thread) · Thread type: M4x0.7 (standard thread) · Thread type: M5x0.8 (standard thread) · Thread type: M6x1 (standard thread) · Thread type: M7x1 (standard thread) · Thread type: M8x1.25 (standard thread) · Drive: External hexagon

Serrated lock washer M4 - M12 galvanized

Ø inside: 4.5 mm · Ø inside: 5.5 mm · Ø inside: 6.35 mm · Ø inside: 7.4 mm · Ø inside: 10.8 mm · Ø inside: 12.8 mm · Material: Steel · Surface: galvanized (blue) · Thread size: M10 · Thread size: M12 · Thread size: M4 · Thread size: M5 · Thread size: M6 · Thread size: M7 · Thread size: M8

Washer M8 large 8.4/20/1.5 Inox

Material: Chrome steel (known as Nirosta®) · Thread size: M8 · Ø inside: 8.4 mm · Nominal diameter (thread): 8 mm · Ø outside: 20 mm · Thickness: 1.5 mm

Flange nut M6 galvanized (strength 10)

Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Nut type: Flange nut · Thread type: M6x1 (standard thread) · Drive: External hexagon · Ø outside: 13.9 mm · Height: 9 mm · Width across flats SW: 10 mm · Strength class: 10

Kraftwerk open-end wrench 4 - 12" (selection) with scale

Width across flats SW: 0 - 14 mm · Manufacturer: Kraftwerk · Area of application: Workshop accessories · Material: Chrome vanadium

Washer M6 Standard (6.4/12/1.6) Inox

Material: Chrome steel (known as Nirosta®) · Thread size: M10 · Thread size: M12 · Thread size: M3 · Thread size: M4 · Thread size: M5 · Thread size: M6 · Thread size: M7 · Thread size: M8 · Hardness [HV]: 140 HV

Nut M6 square low Inox

Material: Chrome steel (known as Nirosta®) · Surface: raw · Area of application: Standard · Nut type: Square nut · Thread type: M6x1 (standard thread) · Drive: External square · Height: 2.9 mm · Width across flats SW: 10 mm · Strength class: A2-70

swiing® revival cable guide mudguard black | Puch

Color: black · Total length: 74 mm · Manufacturer: swiing® revival parts · Number of fixing points: 2 pcs · Hole spacing: 63 mm · Material: Plastic · Height: 12.5 mm · Mounting type: Plug connection

Wippermann drive chain No.18 (double reinforced)

Chain pitch: 1/2" x 3/16" · Chain type: 415H · Manufacturer: Wippermann · Material: Steel · Surface: blank / oiled · Color: gray · Number of chain links: 114 pcs · Rolling circumference: 1448 mm · Chain lock type: Spring lock · Ø bore: 4.2 mm · Ø Pin: 4.15 mm

EBR fork reinforced black | Puch

Manufacturer: EWC · Material: Steel · Surface: chrome-plated · Color: Chrome · Color: black · Ø spars: 28 mm · Spar end distance (center-center): 140 mm · Ø outer head tube: 26 mm · Ø head tube inside: 22 mm · Adjustable: No · Head tube length: 180 mm · Fork bridge - center wheel axle: 381 mm · Thread type: MF26x1 (fine pitch thread) · Distance brake cam to wheel axle center-center: 40 mm · Thread length: 57 mm · Total length: 580 mm

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Material lever: Metal · Mounting type: Union nut · Filter type: Plastic net · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Ø fuel hose connection: 6 mm · Reserve level: 70 mm · Thread type: MF12x1 (fine pitch thread)

GPO rubber for swingarm mounting | Puch Maxi S, X30

Manufacturer: GPO · Material: Rubber · Color: black · Ø inside: 24 mm · Total length: 90 mm · Ø outside: 32 mm · Ø outside: 37 mm · Puch OEM number: 349.1.21.509.1

Sliding bush fork original | Puch

Color: white · Manufacturer: Made in Italy · Material: Plastic · Ø inside: 23 mm · Total length: 30 mm · Ø outside: 27 mm · Puch OEM number: 349.1.30.126.1

swiing® revival bottom bracket bushing nylon | Puch Maxi, X30 Sport, Velux, NG-2AH

Manufacturer: swiing® revival parts · Material: Nylon · Color: black · Surface: blank · Bearing type: Plain bearing · Total length: 19 mm · Ø inside: 16.2 mm · Ø Bundle: 24.1 mm · Ø outside: 20.2 mm · Puch OEM number: 349.1.42.005.1

BING Float seal Bing 85

Manufacturer: BING · Material: Cork · Component group Carburetor: Sealing, revising · Carburetor type: 85

GPO mudguard strut silver | Puch Maxi S, N

Manufacturer: GPO · Material: Steel · Outer width: 25.5 mm · Surface: varnished · Ø mounting hole: 6 mm · Color: silver · Distance mudguard - center hole: 197 mm · Distance mudguard - center hole: 231 mm · Wide intake: 53 mm · Wheel size [inch]: 17 " · Hole spacing: 40 mm · Mounting type: Nuts & bolts · Total length: 240 mm · Number of fixing points: 8 pcs
