AKOA 45 mm cylinder head black | Puch E50 / ZA50 (wind cooled) / ZA50 (cat.) / Z50

swiing® revival stud bolt set M6 x 106 | Puch

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Width across flats: 10 mm · Thread length: 13 mm · Thread length: 18.5 mm · Total length: 106 mm · Drive: External hexagon · Diameter: 5.9 mm · Thread type: M6x1 (standard thread) · Alternative version of the Puch OEM number: 360.1.10.034.1

45 mm gasket cylinder head 0.4 mm | Puch

Place of use: Cylinder head · Material: Aluminum · Ø cylinder: 45 mm · Thickness: 0.4 mm

NGK B7HS spark plug short thread

Manufacturer: NGK · Candle thread type: short · Width across flats: 21 mm · Spark plug socket: M4 · Spark plug socket: SAE · Suppressed: No · Thread type: MF14x1.25 (fine pitch thread)

GPO gasket set cylinder 45 mm Puch

Manufacturer: GPO · Material: Aluminum · Material: Sealing carton · Area of application: Tuning · Ø cylinder: 45 mm · Hole spacing inlet: 38 mm · Hole pattern [mm]: 44 x 44 mm · Number of components: 4 pcs · Hole spacing outlet: 42 mm · Decompressor: Yes

Ripp-Lock washer M6 6.2/14/1.4 galvanized

Material: Steel · Surface: galvanized (blue) · Thread size: M6 · Ø inside: 6.2 mm · Ø outside: 14 mm · Thickness: 1.4 mm · Nominal diameter (thread): 6 mm · Pony OEM number: A1542 · Alternative version of the Pony OEM number: A1644 · Sachs OEM no.: 0244 021 000 · Alternative version of the Sachs OEM number: 0245 023 002

Flange nut M6 galvanized (8 strength)

Material: Steel · Surface: galvanized (blue) · Nut type: Flange nut · Width across flats: 10 mm · Height: 6 mm · Drive: External hexagon · Thread type: M6x1 (standard thread) · Strength class: 8

Solder wire Ø 2 mm Determination of the crimping edge (10 cm piece)

Area of application: Workshop accessories · Total length: 100 mm · Diameter: 2 mm

AKOA 45 mm cylinder kit black CH12 | Puch E50 / ZA50 / Z50

Manufacturer: AKOA · Material: Aluminum · Surface: Nickel silicon carbide (colloquially known as Nikasil) · Displacement: 69 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 47.9 mm · Ø Outlet outside: 24.3 mm · Inlet window: 22.5 x 14.8 · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 38 mm · Ø piston pin (B): 12 mm · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 44 x 44 · Decompressor: No · Camouflaged: No · Area of application: Tuning

swiing® revival stud bolt inlet/outlet M6 x 30 (10.9 strength)

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Thread length: 12 mm · Total length: 30 mm · Diameter: 5.95 mm · Thread type: M6x1 (standard thread) · Strength class: 10.9

swiing® ingenious air filter insert Ø 50 mm "Double Layer"

Manufacturer: swiing® ingenious parts · Material: Foam · Area of application: Tuning · Color: black · Color: red · Ø outside: 50 mm

swiing® ingenious 17 mm SRF carburetor camouflaged | Puch Maxi, Supermaxi, X30 NS / NL

Manufacturer: swiing® ingenious parts · Material: Aluminum · Component group Carburetor: Carburetor complete · Area of application: Tuning · Carburetor type: SRE · Nominal diameter: 17 mm · Width: 47 mm · Total length: 65 mm · Height: 89 mm · Height: 109 mm · Ø fuel hose connection: 5 mm · Ø Internal connection: 23 mm · Ø Inside entrance: 17 mm · Ø Output inside: 17.1 mm · Mounting type: Plug connection clamped · Ø Air filter connection: 27.5 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M3.5x0.6 (standard thread) · Nozzle block: 2.2 · Camouflaged: Yes · Nozzle size: 74 · Clamping screw torque (max.): 3 N/m · Clamping screw torque (max.): 4 N/m

swiing® ingenious intake manifold 17 mm SRF camouflaged | Puch E50

Manufacturer: swiing® ingenious parts · Material: Aluminum · Area of application: Performance · Area of application: Racing · Area of application: Tuning · Ø inside: 17 mm · Ø External connection: 23 mm · Hole spacing inlet: 38 mm · Number of fixing points: 2 pcs · Mounting type: Stud bolts & nuts · Height flange center hole: 42 mm · Total height: 53.5 mm · Total length: 38 mm · Camouflaged: Yes

GEMI screw clamp 20 - 32 mm W2 Inox / galvanized

Manufacturer: GEMI · Material: Chrome steel (colloquially known as stainless steel) · Material: Steel · Surface: galvanized (blue) · Ø inside: 20 - 32 mm · Width: 9 mm

GPO 45 mm piston (Metrakit replica) | Puch

Manufacturer: GPO · Material: Aluminum · Ø outside piston (A): 44.93 mm · Compression height (C): 23.25 mm · Curvature (D): 2.85 mm · Total piston height (E): 49.6 mm · Number of piston rings (F): 2 pcs · Nominal diameter: 45 mm · Piston ring mold: L-ring · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.55 mm · Piston ring height: 2 mm · Thick piston ring: 1.8 mm · Thick piston ring: 1.9 mm · Ø piston pin (B): 12 mm · Weight piston kit: 98 g

GPO gasket set 43.5 & 45 mm (Metrakit replica) | Puch

Manufacturer: GPO · Material: Aluminum · Material: Graphite / Graphite · Material: Sealing carton · Ø cylinder: 43.5 mm · Ø cylinder: 45 mm · Thickness: 0.4 mm · Thickness: 0.5 mm · Thickness: 2.6 mm · Ø outlet inside: 26.5 mm · Hole spacing inlet: 38 mm · Hole pattern [mm]: 44 X 44 · Number of components: 4 pcs · Hole spacing outlet: 42 mm

GPO Ø 45 mm cylinder kit (Metrakit replica) | Puch

Nominal diameter: 45 mm · Manufacturer: GPO · Material: Aluminum · Material: Gray cast iron · Surface: varnished · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 47.8 mm · Ø outlet inside: 26 mm · Ø Inlet inside: 19 mm · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 38 mm · Ø piston pin (B): 12 mm · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 44 x 44 · Camouflaged: No · Area of application: Racing · Area of application: Tuning
