swiing® | One brand. Two approaches.
swiing® ingenious parts
swiing® ingenious crankshaft "High End" C3/4 & FPM (+1 mm stroke) | Puch E50
Manufacturer: swiing® ingenious parts · Weight: 970 g · Cheek type: Full cheeks · Material: Steel · Area of application: High End · Thread type: MF10x1 (fine pitch thread) · Crankshaft stroke: 44 mm · Connecting rod length center-center: 90 mm · Number of gears: 1 pcs · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 66 mm · Ø crank webs: 69.9 mm · Thread length: 11 mm · Ø Connecting rod eye: 15 mm · Thread length: 15 mm · Ø piston pin (B): 12 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm
EUR 256.30
Hot
swiing® ingenious 17 mm SRF carburetor camouflaged | Puch Maxi, Supermaxi, X30 NS / NL
Manufacturer: swiing® ingenious parts · Material: Aluminum · Camouflaged: Yes · Component group Carburetor: Carburetor complete · Carburetor type: SRE · Width: 47 mm · Nominal diameter: 17 mm · Ø Internal connection: 23 mm · Total length: 65 mm · Ø Inside entrance: 17 mm · Ø Output inside: 17.1 mm · Ø Air filter connection: 27.5 mm · Height: 89 mm · Height: 109 mm · Ø fuel hose connection: 5 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M3.5x0.6 (standard thread) · Nozzle block: 2.2 · Nozzle size: 74 · Mounting type: Plug connection clamped · Clamping screw torque (max.): 3 N/m · Clamping screw torque (max.): 4 N/m · Area of application: Tuning
EUR 133.70
swiing® ingenious resonance exhaust set Ø 28 / 70 mm | Puch Maxi, X30 Sport
Manufacturer: swiing® ingenious parts · Material: Steel · Color: Chrome · Surface: chrome-plated · Mounting type: Screwed clamp · Ø outside: 70 mm · Total length: 730 mm · Exhaust type: Cigar · Ø Internal connection: 28 mm · Flame tube attachment: Flange
EUR 133.70
swiing® ingenious 45 mm cylinder kit CH12 camouflaged | Puch
Manufacturer: swiing® ingenious parts · Camouflaged: Yes · Material: Aluminum · Surface: sandblasted · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Nominal diameter: 45 mm · Ø cylinder neck: 48 mm · Ø outlet inside: 25 mm · Number of fixing points: 4 pcs · Inlet window: 23 / 21 x 14 · Thread inlet: M6x1 (standard thread) · Decompressor: No · Ø piston pin (B): 12 mm · Hole pattern [mm]: 44 x 44 · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Area of application: Tuning · Hole spacing inlet: 38 mm
EUR 111.40
Innovation, Expertise und High-End Tuning
swiing® ingenious parts stand for technically advanced components based on existing series parts. Each part is analysed, revised and specifically optimised by our experts to eliminate known weak points. The focus is on improved fit, greater durability and a noticeable increase in performance when driving.
The result is not show pieces, but functional, high-end tuning components that deliver in everyday use and under load. Precise manufacturing, clean materials and practical development ensure that your moped not only feels different, but is also technically improved. swiing® ingenious parts are aimed at riders who value reliable technology and sustainable performance.
swiing® revival parts
swiing® revival wheel axle set front wheel | Piaggio SI
Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Material: Steel · Thread type: MF11x1 (fine pitch thread) · Surface: galvanized (blue) · Ø shaft: 11 mm · Total length: 160 mm · Shank length: 30 mm · Thread length: 65 mm · Ball bearing closed: No · Ø ball [inch] / [mm]: 1/4" (6.35 mm)
EUR 41.10
swiing® revival 17" rear fender set angular | Puch Maxi N
Manufacturer: GPO · Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Material: Steel · Surface: chrome-plated · Surface: polished · Color: Chrome · Wheel size: 17 " · Folding the ends: closed folded · Folding the ends: not folded · Shape of the mudguard: angular · Total length over ends: 625 mm · Mounting type: Nuts & bolts · Scope: 940 mm · Wide mudguard profile: 82 mm · Height of mudguard profile: 35 mm · Total height from support surface to top edge: 285 mm
EUR 52.30
swiing® revival ball bearing countershaft | Sachs 50/2, 50/3, 50/4, 503 2AL/2BL (A2531)
Bearing type: Deep groove ball bearing · Stock number: E15 · Inner ring width: 25.6 mm · Manufacturer: swiing® revival parts · Bearing clearance: CN (standard) · Bearing cage: Sheet steel cage ball-guided · Material: Steel · Ø inside: 15 mm · Width: 8 mm · Thread type: MF20.8x1 LH (fine/left-hand thread) · Ø outside: 35 mm · Area of application: High End · Area of application: Standard · Pony OEM number: A2531 · Sachs OEM no.: 0286 079 105
EUR 55.60
swiing® revival lamp holder without brackets Inox | Piaggio Ciao PX / C24
Manufacturer: swiing® revival parts · Mounting type: Screws · Material: Chrome steel (colloquially known as stainless steel) · Thread size: M6 · Wide intake: 101 mm · Number of fixing points: 3 pcs · Piaggio OEM number: 247947
EUR 27.80
Revived original parts of the highest quality
With swiing® revival parts, we make original spare parts available again that are now difficult or impossible to find. The aim is to keep classic mopeds roadworthy and preserve their original character. The form, function and appearance are consistently based on the original.
Each Revival Part is newly manufactured and carefully tested. High-quality materials and precise workmanship ensure that the parts not only look original, but also meet the demands of everyday riding today. Where appropriate, subtle technical improvements are incorporated without changing the appearance. The result is spare parts that do justice to the original and impress in the long term.
GPO tuning set 45 mm (Metrakit replica) | Puch E50
Manufacturer: GPO · Camouflaged: No · Material: Aluminum · Material: Gray cast iron · Material: Steel · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Nominal diameter: 45 mm · Ø cylinder neck: 47.8 mm · Decompressor: No · Hole pattern [mm]: 44 x 44 · Outlet type: straight · Area of application: Racing · Area of application: Tuning
EUR 444.80
GPO clutch facings mono with reinforced springs & starter bell | Piaggio Ciao, SI, Bravo, Boxer
Manufacturer: GPO · Material: Aluminum · Material: Composite materials · Material: Spring steel · Material: Steel · Surface: varnished · Recording type: 2-edge · Number of jaws: 3 pcs · Number of springs: 6 pcs · Area of application: Tuning · Piaggio OEM number: 104480 · Piaggio OEM number: 114943 · Alternative version of the Piaggio OEM number: 121753
EUR 47.80
New
Hot
43.5 mm cylinder head CNC Tuning | Puch E50
Manufacturer: Made in Switzerland · Total length: 169 mm · Width: 164 mm · Material: Aluminum · Ø cylinder: 43.5 mm · Area of application: Tuning · Candle thread: short · Height: 50.6 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 44 x 44 · Decompressor: No
EUR 211.70
GPO clutch facings mono with reinforced springs | Piaggio Ciao, SI, Bravo, Boxer
Manufacturer: GPO · Material: Aluminum · Material: Composite materials · Material: Spring steel · Area of application: Tuning · Surface: varnished · Number of springs: 6 pcs · Number of jaws: 3 pcs · Thickness: 14 mm · Piaggio OEM number: 104480 · Alternative version of the Piaggio OEM number: 121753
EUR 37.80
Starter shaft with drive pinion (pedal) original | Tomos Standard, Flexer, Youngster
Manufacturer: Tomos · Material: Steel · Ø Shaft: 15.8 mm · Number of teeth: 25 pcs · Total length: 245 mm · Tomos OEM number: 032073 · Tomos OEM number: 217584 · Tomos OEM number: 223448 · Tomos OEM number: 1232658
EUR 144.80
swiing® revival repair kit main stand | Piaggio Bravo, SUPERbravo
Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Material: Spring steel · Material: Steel · Surface: galvanized (blue) · Surface: stainless · Total length: 112 mm · Width: 14 mm · Mounting type: Circlip · Number of fixing points: 2 pcs · Piaggio OEM number: 214490 · Piaggio OEM number: 226667 · Piaggio OEM number: 226668
EUR 18.80
swiing® ingenious air filter insert "Racing" | Sachs 503 AB / ABL, 504, 505
Manufacturer: swiing® ingenious parts · Material: Paper · Material: Rubber · Color: black · Color: yellow · Ø inside: 27 mm · Total length: 58 mm · Width: 58 mm · Height: 65 mm · Ø outside: 50 mm · Mounting type: inserted · Area of application: Racing · Area of application: Tuning · Alternative version of the Pony OEM number: A4336 · Alternative version of the Sachs OEM number: 0225 010 100
EUR 13.30
Collection only possible with online purchase and appointment.
